IP
65 GRADE |
MATERIAL | AL. Die-Casting |
REFLECTOR | AL. Anodized |
BEAM
ANGLE | 15° / 24° / 38° / 60° |
BODY
COLOR | WHITE |
LIGHT
SOURCE | LED COB(CHIP ON BOARD) |
COLOR
RENDERING INDEX | 80 Ra / 90 Ra |
COLOR
TEMPERATURE | 2700K/3000K/3500K/4000K/5700K |
INPUT
VOLTAGE | 220-240V AC , 50/60Hz |
OUTPUT
POWER | 10W / 15W / 20W / 30W |
OUTPUT
VOLTAGE | 36V DC |
OUTPUT
CURRENT | 250mA/ 350mA/ 500mA/ 700mA |
SYSTEM
EFFICIENCY | 100 lm/w(3000K) |
LUMINOUS
FLUX | 1000 lm/1500 lm/2000 lm/3000 lm |
OP.
TEMPERATURE RANGE | -20 to +40℃ |
IP GRADE | 65 |
LIFE
TIME | Up to 50,000 hours |
SMPS
OPTION | ON OFF/ DALI/ TRIAC/ 0-10V/
1-10V |
ACCESSORY | Honeycomb / Safety glass
diffuser |
